Specs
General Specs
Wall Cabinet
Interior Finished To Match Frame
No Door
Width - 27 inches
Depth - 12 inches
Height - 30 inches
Additional Specs
No Door open cabinet interiors and shelves will be finished to match the face frame color *The interior of No Door cabinets will not match the door finish/texture.
Matching End Panels or Cover Panels are optional but recommended if the cabinet will be on the end of a run or exposed in any way.
Shelf adjustment holes will be visible on the inside walls and back panel of the cabinet.
Two color matched adjustable shelves
Minimum total pull - 25"
Maximum total pull - 30"
Atleast 3" of filler required between this cabinet and the adjacent cabinet on the other wall
3" color matched to face frame filler, 3" & 6" color matched to doors overlay fillers, and 3/16" blind closure panel included
Cabinet can be pulled for exact fit (see installation guide)
